CNC Wood Turning Lathe Machine with Central Point Fix Device

Cnc Wood Turning Lathe Machine with Central Point Fix Device
  • Model：CT-1512-3S-AUTO
  • Supplity：360 Units in Stock Available for Sale Every Month
  • Standard:Meeting CE Standards in Terms of Quality & Safety
  • Function Description

The CNC Wood Turning Lathe Machine with Central Point Fix Device is designed for precise and efficient turning of stair spindles, furniture legs, table posts, chair legs, bed posts, baseball bats, and other custom wood parts. With its stable center fixing system, heavy-duty frame, and easy CNC control, it delivers smooth, accurate results on softwoods and hardwoods for both small batches and large-scale woodturning jobs.

SEND AN EMAIL
WHATSAPP
Huge-facebook-02 Huge-tiktok Huge-youtube Huge-twitter

Features Videos of CNC wood lathe

Perfect for turning and shaping stair spindles, furniture legs, table posts, chair legs, bed posts, handrails, baseball bats, and other custom cylindrical or tapered wood parts with precise center fixing for stable, accurate production.

cnc Lathe Turning Machine
Cnc Lathe
cnc Lathe Machine
wood Lathe

Introduction of CNC Wood Turning Lathe Machine with Central Point Fix Device

  • Flexible Working Size
    Offers a maximum turning length of 1500 mm. While using the three-axis configuration, the turning diameter can reach up to 120 mm; in single-axis mode, it can handle larger diameters up to 300 mm, meeting various production needs.
  • Heavy-Duty Cast Iron Bed
    The machine body is built with a solid cast iron lathe bed, treated with high-temperature annealing and vibration stress relief to ensure long-term stability and eliminate any risk of deformation.
  • User-Friendly DSP Control System
    Equipped with an advanced DSP controller and a wireless handheld pendant, making operation, calibration, and adjustments simple and convenient.
  • High-Precision Motion Components
    Features a high-quality TBI ball screw and Taiwan Hiwin square linear guide rails, delivering excellent accuracy, smooth movement, and an extended service life.
  • Dual-Sided Cutting Tool Design
    The lathe is fitted with six cutters on both sides — the roughing and finishing knives work in a layered sequence, greatly improving processing efficiency and ensuring superior surface finish quality.
  • Adjustable Rotation Speed
    The spindle speed is easily adjustable using an inverter, with real-time speed data displayed clearly on the control cabinet panel for better control and monitoring.
  • Multi-Function Machining
    Combines turning, broaching, and engraving in a single setup at high speeds, making it versatile and cost-effective for producing complex wood components.

Specification of CNC Wood Turning Lathe Machine with Central Point Fix Device

ItemDetails
ModelCT-1512-3S-AUTO
Working Length (mm)Up to 1500 mm
Max Swing Over BedMaximum 300 mm for single workpiece; up to 120 mm diameter for three pieces simultaneously
Center HoldingIncludes fixed center positioning device
Power Supply380 V / 50 Hz
Control System OptionsA: 12-inch full-color CNC computer control panel OR B: DSP handheld controller with USB port
Guide Rails & Ball ScrewsFitted with high-quality imported square linear guide rails and precision ball screws
Steady RestRotary center — supports 50 mm and 60 mm wood blanks
Self-Centering FeedAutomatic foot-controlled pneumatic centering and feeding system
Spindle Motor4-pole frequency-controlled spindle, 380 V
Frequency InverterVector-controlled electronic inverter with automatic braking function
TailstockPneumatic tailstock for secure material clamping
Tool SetupFactory-installed V-shaped steel turning tools with welded alloy knife edges
SoftwareIntuitive CNC software with easy operation; supports basic map file import
Accessory ToolsSupplied with standard tool wrenches
Additional FunctionsEngraving, pull-through turning, twisting; flexible spindle control
Extra AttachmentUniversal rotary joint for additional pull-through operations

Application of CNC Wood Turning Lathe Machine with Central Point Fix Device

Supported Materials

This CNC wood turning lathe can handle a wide variety of materials for both softwood and hardwood applications. Suitable materials include pine wood, beech wood, oak wood, mahogany, camphor wood, birch, rosewood, lime wood, teak wood, and other solid woods. It is also capable of processing synthetic materials such as artificial marble, crystal acrylic, resin glass, and similar composites, allowing for diverse custom woodturning and decorative projects.

Application Areas

The machine is widely used in furniture production, stair part manufacturing, architectural millwork, and custom woodcraft industries. Typical workpieces include:

  • Wooden staircase components like balusters, handrails, newel posts, and spindles
  • Furniture legs for tables, sofas, beds, chairs, stools, and benches
  • Decorative columns, Roman pillars, pavilion spires, and porch posts
  • Sporting goods such as baseball bats, billiard cues, drumsticks, and flagpoles
  • Household items including rolling pins, wooden brush handles, coat rack spindles, and wooden vases
  • Unique turned wood crafts for custom interior and exterior design elements

Whether you are producing traditional staircase handrails, custom furniture legs, or artistic wooden ornaments, this CNC wood lathe machine delivers high precision, smooth surface finishes, and consistent quality across various shapes and materials.
